Hey there,
If you’re here, you’re probably dealing with a problem that hits way too hard: your fixed axial fans are either underperforming, creating unnecessary noise, or just not pulling their weight when you need them most. Let me guess—you probably got a fan that’s supposed to move 10,000 CFM, but in practice, it’s barely moving half that, and you’re staring at your utility bill wondering if you should just buy a new one (spoiler: maybe not yet). I’ve been in this space for years, as a fixed axial fan supplier, and let me tell you—9 times out of 10, the issue isn’t the fan itself. It’s where you put it. Fixed Axial Fans
A lot of folks skip this step, right? They unbox the fan, drill a hole in the wall or roof, and bolt it on like it’s just another shelf. But axial fans aren’t that passive. They rely on air pressure, obstructions, and how they interface with the surrounding space to do their job. Mess up the installation spot, and even the best fixed axial fan on the market will end up a waste of time and money. Let’s break this down into the stuff that actually matters—no jargon, no corporate fluff, just real advice I’ve handed to clients who went from complaining about their fans to coming back for replacements because their setup finally clicked.
First, let’s talk about the biggest killer of axial fan performance: obstructions. I see this all the time. Someone installs a fan on a wall that’s right next to a metal duct, a stack of pallets, or even a support beam—like, 6 inches away. Here’s the thing: axial fans move air in a straight line (well, as straight as they can) when they’re operating optimally. If there’s something blocking that air stream within 2 feet of the fan inlet or outlet, it’s creating what’s called “pressure drag.” Think of it like blowing into a straw that’s crumpled in the middle—you’re putting in all the effort, but almost no air comes out.
I had a client last year, a small manufacturing shop that makes custom cabinet parts. They had three fixed axial fans on their warehouse wall, each next to a structural column they’d built to support the roof. They called me up saying the fans were only moving 4,000 CFM each, when their spec sheet said they should do 8,000. I went to take a look, and boom—each column was 12 inches wide, and the fan was only 10 inches away from the fan outlet. We had them move the fans 3 feet away from the columns, and within a week, their CFM numbers doubled. No new fans, just moving them a little bit. That’s the kind of win we’re talking about here.
Rule of thumb for obstructions: keep at least 2 feet of clear space on the inlet side (that’s the side the air is being pulled into) and 3 feet on the outlet side (the side blowing air out). If you can’t move the fan because of ductwork or existing walls, get a short, straight duct extension for the outlet—just make sure it’s smooth, not crinkled. Even a 1-foot extension that removes the fan from the tight wall gap makes a huge difference.
Next up, matching the fan to the space’s airflow needs. This is where a lot of people get tripped up, especially if they’re using fixed axial fans in weird spaces—like a tiny server closet, a loading bay, or a small agricultural greenhouse. Let’s be real: if you put an 18-inch fixed axial fan in a 4×4 closet that only needs to cool down to prevent server overheating, it’s going to push air so hard it creates backpressure. Backpressure is the exact opposite of what you want—when the air the fan is blowing can’t escape, it pushes back against the blades, making the fan work way harder than it needs to, wasting energy, and wearing out faster.
I’ve had people ask me, “Can I just put a bigger fan to fix a small space?” The short answer: no. Bigger isn’t always better here. You need to calculate the “air changes per hour” (ACH) for your space. For example, a typical garage or small warehouse might need 6-12 ACH, while a server closet needs 20-30 ACH. Let’s do a quick math check: if your space is 10ft wide, 20ft long, 8ft tall, that’s 1,600 cubic feet total. If you need 8 ACH, you need a fan that moves at least (1,600 * 8)/60 = ~213 CFM. A fixed axial fan that’s too big for that space would be overkill—you’d end up with backpressure, higher electric bills, and a fan that burns out sooner.
Also, don’t forget about the direction the fan is facing relative to prevailing wind if it’s installed outdoors (like on a building’s roof or exterior wall). Wait—axial fans work outdoors too? Absolutely, a lot of our fixed axial fans go to outdoor applications like rooftop ventilation, loading bay exhaust, or greenhouse venting. If you mount the outlet side of the fan facing into a consistent wind (say, a wind that blows from north to south all year), that wind is going to push against the fan’s outgoing air, creating even more backpressure. Instead, face the fan outlet away from the prevailing wind. If you’re not sure what that is, check your local weather data—most areas have average wind direction stats from the last 5 or 10 years. Even turning it 15 degrees can cut backpressure by 20% or more.
Another thing no one talks about: mounting height. I know it seems trivial, but it’s actually super important, especially for spaces that are high-ceilinged or have uneven air flow. Let’s take a warehouse with a 20-foot ceiling, for example. If you mount a fixed axial fan at 8 feet high, it’s only moving air around the lower 8 feet of the space—all the hot air that rises to the ceiling is just sitting there, right where people aren’t. Mount the fan higher, around 15 feet (but still keeping that outlet clearance), and it can pull that hot ceiling air down and circulate it through the whole space.
I had a greenhouse client a few months back—they had their fixed axial fans mounted at the wall, 6 feet high, and their tomato plants were wilting at the top of the rows. We moved two of the fans up to 12 feet, with small duct extensions pointing them at the upper plant canopy, and within two weeks, the wilting stopped. Their overall humidity dropped too, which cut down on fungus issues—win, win. The key here: for spaces where heat or fumes rise (warehouses, greenhouses, manufacturing floors), mount the fan high enough to pull that air before it gets trapped. For spaces that need to cool lower areas (like server rooms or small offices), mount the fan 7-10 feet high, so it can circulate air where people/equipment are.
Wait, what about when you’re mounting a fan between two rooms or in a duct? Let’s say you’re using a fixed axial fan to pull fumes out of a small paint booth into the main shop space. Don’t mount the fan directly between the booth and the shop—make sure there’s a damper or a filter on the outlet side that’s the same size as the fan. If the filter is smaller, that’s an obstruction, plain and simple. Also, if you’re running the fan in a duct, keep the duct runs as straight as possible, no sharp 90-degree turns. If you have to turn, use a gradual 45-degree bend to keep air flow smooth. Sharp turns create turbulence, which kills performance—same as a crumpled straw.
Oh, and let’s not forget about the surrounding surfaces. A lot of people mount fixed axial fans on thin metal siding or a flimsy plywood wall that vibrates when the fan runs. Not only is that annoying noise pollution, but over time, all that vibration can loosen the fan’s mount, leading to misalignment and even more performance drops. If you’re mounting on a thin wall, use a reinforcing plate behind the fan—something like a 12×12 inch metal plate—so the vibration is distributed, not focused on a small spot. Also, if you’re in a noisy area, consider mounting the fan slightly recessed into the wall, so the fan’s housing is inside the wall cavity, not sticking out. That cuts down on the noise by 5-10 decibels, which is the difference between a fan that’s a background hum and one that’s driving your whole team crazy.
I’ve seen so many clients waste hundreds (sometimes thousands) of dollars on bad fan installations. They buy a premium fixed axial fan, read the spec sheet, but skip the location part, and end up with a fan that’s underperforming. The good news is, optimizing the installation location is free (or super cheap) if you know what to look for. It’s not about getting the most expensive fan—it’s about getting the right fan in the right spot.
If you’re unsure about your current setup, or you’re picking out a new fixed axial fan and want to make sure you’re mounting it right, reach out to our team. We’ve worked with everything from small garages to large manufacturing facilities, and we can help you size the fan, pick the best spot, and even give you tips for mounting that’ll get you maximum performance with minimal hassle. No pressure, just honest advice—we’ve been doing this long enough to know that happy customers come from getting their fans working, not just selling them a product.
Don’t let a bad installation ruin your fan’s performance. Take 10 minutes to check the clearances, measure your space’s needs, and pick the right spot. It’ll save you money on electric bills, extend your fan’s life, and make your space way more comfortable (and efficient).
If you’re ready to upgrade your fixed axial fans or get help with installation planning, our team is here to help. Reach out to us for a consultation, and we’ll walk through your space with you to make sure your fans are doing exactly what they’re supposed to.
Single Stage Regenerative Blowers References:
ASHRAE Handbook of Fundamentals, 2021
Industrial Ventilation: A Manual of Recommended Practice, 30th Edition
Fixed Axial Fan Performance Standards, AMCA International, 2022
